Product: Microweily TY-2080 Lathe
510mm swing over bed, 330mm swing over cross slide, 680mm in gap diameter, 255mm centre height, 2040mm between centres, 2 axis Mitutoyo DRO
New Microweily TY-2080 Centre Lathe.
Features and inclusions:
- 510mm swing over bed
- 330mm swing over cross slide
- 680mm in gap diameter
- 255mm centre height
- 2040mm between centres
- 400mm bed width
- 80mm spindle bore
- D1-8 spindle nose
- 20-1550rpm spindle speed (12)
- 75mm tailstock quill diameter
- 160mm tailstock quill travel
- MT5 tailstock taper
- 15HP main motor
- Mitutoyo 2 axis DRO
- Follow rest x 1 qty
- Steady Rest x 1 qty
- 12 inch 3 jaw self centering chuck
- 16 inch 4 jaw independent chuck
- 20 inch Face plate
- Rear splash guard
- Headstock chuck guard with micro switch
- Quick change tool post with 6 holders
- Halogen lamp
- Leadscrew guard
- CE electrics
- Machine size: 3558 x 1280 x 1255mm
- Machine weight: 2480kg
