Yawei PBA 63-2050 CNC3

NEW Machtech Yawei Synchro PBAS 35-1250 CNC4 Pressbrake.

Features include:

• 35 ton bending force
• 1250mm maximum bending length
• 950mm between frames
• 300mm throat
• 120mm ram stroke
• 450mm open height
• 4 axis CNC: Y1, Y2, X & R
• 2 backgauge fingers moving freely on linear guide
• 2 front sheet supports free moving on linear guide

Tooling:

• Rolleri (Italy) top and bottom tooling
• quick clamps

Controller:

• Delem DA-52S CNC control
• pendant mounted
• capable of controlling 4 axes
• equipped with Delem user-friendly interface including hotkey navigation
• USB interface enables quick and easy memory stick backup of product and tool information
• 6.4 inch VGA colour TFT

Guards:

• Lazersafe light guards
• rear and side physical guards with safety interlock

General:

• Hoerbiger hydraulic system (Germany)
• ballscrew backgauge, AC servo motor driven and running on a linear guide.
• motor power: 4kW
• machine size: 1720 x 1390 x 2340mm
• machine weight: 2700kg
